I-Frame Only H.264 Encoder Core for FPGA's

H.264 I-Frame Only ENCODER FPGA Core - High Speed Micro Footprint

Our I-Frame Only FPGA core is highly optimized to be as fast and small as possible. By limiting the core to using only I-Frames, we were able to reduce the size of the core by 30% (compared to our already small H.264 Encoder Core) achieving a size close to that of a JPEG Encoder, yet provide much better compression! If you need a small, fast core with better compression than JPEG, this may be your best solution.


It is capable of being synthesized in many FPGAs and supports H.264 variable and fixed bit-rate encoding of video streams. Encodes video data at 1.5 clocks/pixel. Typical clock rate in an Xilinx SPARTAN 6 is 95Mhz. Typical clock rate in a Xilinx Zynq 7020 is 95MHz. Multiple cores can be used for processing larger size or higher frame rate images. Uses FPGA specific DDR 3 controller and microprocessor soft core. In addition, the standard core can be customized, retaining ITAR compliance, to meet unique functional needs.


Features

  • 1.5 clocks/pixel processing rate
  • Fully compatible with the ITU-T H.264 specification
  • Available with bus widths from 8-12 to handle deeper pixel depths (Pre-compiled for Binary license.)
  • Supports resolutions up to 4096 x 4096 (can be expanded with additional cores)
  • Supports simultaneous encoding of multiple streams of arbitrary sizes and compression ratios
  • Generates I frames only
  • Variable Bit Rate (VBR) and Constant Bit Rate (CBR)
  • Search range: 80 X 48 pixels, Full, 1/2, 1/4 pixel resolution
  • Entropy Encoding: CAVLC
  • Support for intra 4 x 4 DC prediction
  • Support for Single or Multiple slices via firmware control
  • Supports YUV 4:2:0 video input
  • Fully synchronous design
  • Available as FPGA specific netlist
  • Custom versions available

Additional Features

  • Xilinx AXI Bus Support

Deliverables

  • FPGA specific netlist
  • Bit accurate C model
  • Complete HDLtestbench
  • Test images
  • Complete data sheet

Licensing Options

  • Evaluation
  • Development
  • Project
  • Unlimited

Xilinx

  • Spartan 6
  • Virtrex 6 & 7
  • Kintex
  • Artix
  • Zynq
  • Virtex 4QV & 5QV (Rad Hard)

Altera/Intel

  • Cyclone V
  • Arria
  • Stratix

Why use an A2e FPGA Core vs DaVinci/iMx6?


Get the Data Sheet!

The Data Sheet contains more details on functionality and deliverables. Please email sales to learn more. (sales@A2eTechnologies.com
